2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s) 4 x SATA 3Gb/s connector(s) 1 x CPU Fan connector(s) 1 x Chassis Fan connector(s) 1 x 24-pin EATX Power connector(s) 1 x 4-pin ATX 12V Power connector(s) 1 x Front panel audio connector(s) (AAFP) 1 x Internal speaker connector(s) 1 x System panel(s)
Realtek® ALC887 8-Channel High Definition Audio CODEC
1 x PS/2 keyboard (purple) 1 x PS/2 mouse (green) 1 x D-Sub 1 x LAN (RJ45) port(s) 4 x USB 2.0 1 x COM port(s) 3 x Audio jack(s)
16 Mb Flash ROM, AMI BIOS , PnP, DMI v2.0, WfM2.0, SM BIOS V2.7, ACPI V2.0a
4 x SATA 3Gb/s port(s), blue Support Raid 0, 1, 10, JBOD
ASUS EPU : - EPU Core Unlocker ASUS Exclusive Features : - Anti-Surge ASUS Quiet Thermal Solution : - ASUS Fan Xpert ASUS EZ DIY : - ASUS CrashFree BIOS 3 - ASUS EZ Flash 2 - ASUS MyLogo 2
Integrated ATI Radeon™ HD 3000 GPU VGA output support : RGB port - Supports RGB with max. resolution 2560 x 1440 @ 75 Hz Maximum shared memory of 1024 MB Hybrid CrossFireX™ Support *1 Supports DirectX 10
24.4 cm x 18.8 cm
Akcesoria: User's manual I/O Shield 2 x SATA 3Gb/s cable(s)
