- CPU
AMD Socket AM3 ;Phenom™II /Athlon™II /Sempron™ 100 Series Processors
Supports 45nm CPU
AMD Cool 'n' Quiet™ Technology
- Chipset
AMD 880G/SB850
- System Bus
Up to 5200 MT/s ; HyperTransport™ 3.0
- Memory
4 x DIMM, Max. 16 GB, DDR3 2000(O.C.)/1600/[zasłonięte]/1066 ECC,Non-ECC,Un-buffered Memory
Dual Channel memory architecture
*Due to CPU spec., AMD 100 and 200 series CPUs support up to DDR3 1066Mhz. With ASUS design, this motherboard can support up to DDR3 1333MHz.
**Due to OS limitation, when installing total memory of 4GB capacity or more, Windows® 32-bit operation system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended.
***Refer to www.asus.com for the memory QVL (Qualified Vendors Lists).
- Expansion Slots
1 x PCIe 2.0 x16
2 x PCIe 2.0 x1
1 x PCI
- VGA
Integrated ATI Radeon™ HD 4250 GPU
SidePort Memory - onboard 128MB DDR3 1333 memory
Dual independent displays support with HDMI/DVI and D-Sub
Supports HDMI with max. resolution 1920 x 1200 (1080P)
Supports DVI with max. resolution 2560x1600 @60Hz
Supports D-Sub with max. resolution 2560x1440 @75Hz
Supports Microsoft® DirectX 10.1, OpenGL 2.0, Shader Model 4.1
Hardware Decode Acceleration for H.264, VC-1, and MPEG-2
Max. shared memory of 1GB
Hybrid CrossFireX™ Support
- Storage
SB850 Chipset
5 xSATA 6.0 Gb/s ports Support RAID 0,1,5,10
1 x eSATA port (6Gb/s ready)
VIA VT6415 PATA controller
1 xUltraDMA 133/100 for up to 2 PATA devices
- LAN
Realtek® 8111E Gigabit LAN controller featuring AI NET2
- Audio
Realtek® ALC 892 8-Channel High Definition Audio CODEC
- Supports 192kHz/ 24bit BD Lossless Sound
- Supports Jack-Detection, Multi-Streaming, and Front Panel Jack-Retasking
- Optical S/PDIF Out port at back I/O
- IEEE 1394
VIA® VT6315N controller supports 2 x 1394a port(s) (1 at mid-board, 1 at back panel)
- USB
2 x USB 3.0 ports (@PCIE USB3 card)
14 x USB 2.0/1.1 ports (8 ports at mid-board, 6 ports at back panel)
- ASUS Unique Features
ASUS Xtreme Design
ASUS Hybrid Processor - TurboV EVO
- Turbo Unlocker, Auto Tuning, TurboV, CPU Level UP, and GPU Boost
ASUS Hybrid Switch
- Core Unlocker
- Turbo Key II
ASUS Hybrid OS -- Express Gate
ASUS Power Solutions
- 4+1 Phase Power Design
- ASUS Anti-Surge Protection
- ASUS EPU
ASUS Exclusive Features
- MemOK!
ASUS Quiet Thermal Solution
- ASUS Fanless Design: Heat sink solution
- ASUS FanXpert
ASUS EZ DIY
- ASUS Q-Shield
- ASUS O.C. Profile
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS MyLogo 2
- Multi-language BIOS
- Overclocking Features
Precision Tweaker 2
- vCore: Adjustable CPU voltage at 0.003125V increment
- vDIMM: 64-step DRAM voltage control
- vChipset (NB): 64-step Chipset voltage control
SFS (Stepless Frequency Selection)
- PCI Express frequency tuning from 100MHz up to 150MHz at 1MHz increment
- HT tuning from 100MHz up to 550MHz at 1MHz increment
Overclocking Protection
- ASUS C.P.R.(CPU Parameter Recall)
- Back Panel I/O Ports
1 x PS/2 Keyboard/Mouse Combo port
1 x DVI
1 x D-Sub
1 x HDMI
1 x External SATA
1 x S/PDIF Out (Optical)
1 x IEEE 1394a
1 x LAN(RJ45) port
8 -Channel Audio I/O
2 x USB 3.0 ports (@PCIE USB3 card)
6 x USB 2.0/1.1 ports
- Internal I/O Connectors
4 x USB connectors support additional 8 USB 2.0/1.1 ports
1 x IDE connector
5 x SATA 6Gb/s connectors
1 x CPU Fan connector
1 x Chassis Fan connector
1 x Power Fan connector
1 x IEEE1394a connector
1 x S/PDIF Out Header
1 x Core Unlocker Switch
1 x Turbo Key II Switch
1 x MemOK! Button
Front panel audio connector
1 x COM connector
1 x LPT connector
1 x Clear CMOS jumper
1 x 24-pin ATX Power connector
1 x 4-pin ATX 12V Power connector
System Panel
