AMD Socket AM2+ / AM2 Phenom™ X4/Phenom™ X3/Athlon™ /Athlon™ X2/Sempron™ Processors
Support AM3 Phenom™ II / Athlon™ X4 / Athlon™ X3 / Athlon™ X2 Processors
AMD Cool 'n' Quiet™ Technology
Support 45nm CPU

AMD 780G/SB700

Up to 5200 MT/s for AM3 /AM2+ CPU
2000 / 1600 MT/s for AM2 CPU
HyperTransport™ 3.0

4 x DIMM, Max. 16 GB, DDR2 1066/800/667 ECC,Non-ECC,Un-buffered Memory
Dual Channel memory architecture
*Due to AMD CPU limitation, DDR2 1066 is supported by AM3/AM2+ CPU for one DIMM per channel only.
**Due to OS limitation, when installing total memory of 4GB capacity or more, Windows® 32-bit operation system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended.
***Refer to www.asus.com or the user manual for the Memory QVL (Qualified Vendors Lidts)

1 x PCIe 2.0 x16
2 x PCIe x1
1 x PCI 2.2

Integrated ATI Radeon™ HD 3200 GPU
Max. shared memory: 256 MB
- Supports HDMI™ Technology with max. resolution up to 1920 x 1200 (1080P)
- Supports Dual-link DVI with max. resolution up to 2560x1600 @60Hz
- Supports D-Sub with max. resolution up to 2560x1440 @75Hz for 16:9 format
- Hybrid CrossFireX™ Support
- Dual independent displays support with HDMI/DVI and D-Sub
- Supports Microsoft® DirectX 10, OpenGL 2.0, Pixel Shader 4.0
- Hardware Decode Acceleration for H.264, VC-1, and MPEG-2

SB700 Chipset
1 xUltraDMA 133/100/66 for up to 2 PATA devices
5 xSATA 3 Gb/s ports Support RAID 0,1,10
1 x external SATA 3Gb/s ports

** Due to the Windows XP/ Vista limitation, the RAID array with the total capacity over 2TB cannot be set as a boot disk. A RAID array over 2TB can only be set as a data disk only.

Atheros L1E Gigabit LAN controller featuring AI NET 2

8 -Channel High Definition Audio CODEC
- Supports Jack-Detection, Multi-Streaming
- Coaxial and Optical S/PDIF Out ports at back I/O
- DTS Surround Sensation Ultra PC
- 2-ch Gold-plated RCA output at back I/O
- ASUS Noise Filtering

10 USB 2.0 ports (6 ports at mid-board, 4 ports at back panel)

ASUS HTPC Features
- ASUS Absolute Pitch Hi-Fi
- ASUS Home Theater Gate
- ASUS Tranquil Mode (for AM3/AM2+ CPU only)
- DTS Surround Sensation Ultra PC
ASUS Quiet Thermal Solution
- ASUS Fanless Design: Soundwave Heat-sink solution
ASUS Express Gate
ASUS EZ DIY:
- ASUS Q-Connector
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS MyLogo 2

Precision Tweaker
- vCore: Adjustable CPU voltage at 0.05V increment
SFS (Stepless Frequency Selection)
- FSB tuning from 200MHz up to 550MHz at 1MHz increment
- PCI Express frequency tuning from 100MHz up to 150MHz at 1MHz increment
- GPU tuning from 500MHz up to 999MHz
Overclocking Protection
- ASUS C.P.R.(CPU Parameter Recall)

1 x DVI
1 x D-Sub
1 x HDMI
1 x External SATA
4 x USB 2.0/1.1
8 -Channel Audio I/O
1 x Coaxial S/PDIF Out
1 x Optical S/PDIF Out
2-ch RCA auido output connectors

3 x USB connectors (6 ports)
1 x IDE connector
5 x SATA connectors
1 x CPU Fan connector
2 x Chassis Fan connector
1 x Power Fan connector
1 x S/PDIF Out connector
Front panel audio connector
System Panel
CD audio in
24-pin ATX Power connector
4-pin ATX 12V Power connector
4-pin ATX 12V Audio power connector
