| Procesor |
AMD AM3/AM2+/AM2 ;Phenom™II /Athlon™II /Phenom™ / Athlon™ /Sempron™ Processors
AMD 140W CPU Support
AMD Cool'n'Quiet™ Technology |
| Chipset |
AMD 770/SB710
|
| Magistrala systemowa |
Up to 5200 MT/s ; HyperTransport™ 3.0 interface for AM2+(Up to AM3) CPU |
| Pamięć |
4 x DIMM, Max. 16 GB, DDR2 1200(O.C.)/1066/800/667/533 ECC,Non-ECC,Un-buffered Memory
Dual Channel memory architecture
*Due to AMD CPU limitation, DDR2 1066 is supported by AM2+ /AM3 CPU for one DIMM per channel only.
*Refer to www.asus.com for the memory QVL (Qualified Vendors List) |
| Porty rozszerzeń |
1 x PCIe x16
2 x PCIe x1
3 x PCI
|
| Pamięć masowa |
Southbridge
1 xUltraDMA 133/100/66
6 xSATA 3 Gb/s ports Support RAID 0,1,0+1,JBOD
|
| Sieć LAN |
RTL8112L PCIe Gigabit LAN |
| Karta dźwiękowa |
VT1818S High Definition Audio 8-Channel CODEC
- Blu-ray disc audio layer Content Protection
- Optical S/PDIF out port at back I/O
- Support Jack-detection, Multi-streaming, and Front Panel Jack-Retasking technologies |
| USB |
12 USB 2.0/1.1 ports (6 ports on mid-board,6 ports on back panel) |
| Unikalne funkcje firmy ASUS |
ASUS Quiet Thermal Solution:
- ASUS Q-Fan
ASUS EZ DIY:
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
ASUS AI NET 2
Stack Cool3
Turbo Key
ASUS MyLogo 2
EPU 4-Engine
ASUS Express Gate
|
| Porty tylnego panelu I/O |
1 x Parallel port
1 x PS/2 Keyboard
1 x S/PDIF Out
1 x IEEE 1394a
1 x LAN(RJ45) port
6 x USB 2.0/1.1
1 x COM port
8 -Channel Audio I/O
|
| Złącza I/O na płycie |
3 x USB connectors for 6 additional USB 2.0 ports
1 x IDE connector
6 x SATA connectors
1 x CPU Fan connector
1 x Chassis Fan connector
1 x High Definition front panel audio connector
1 x System Panel connector
1 x 4 pin, ATX + 12V, power connector
1 x 24pin, EPS 12V power connector
1 x S/PDIF output connector
|
| BIOS |
8 Mb Flash ROM , AMI BIOS Pnp, DMI v2.0, Wfm2.0, ACPI v2.0a, SMBIOS V2.5
|
| Akcesoria |
User's manual
1 x UltraDMA 133/100/66 cable
2 x SATA cable(s)
I/O Shield
|
| Płyta „Support CD" |
Drivers
ASUS PC Probe II
Anti-virus software (OEM version)
ASUS Update
|
| Format płyty |
ATX Form Factor
12 inch x 8.4 inch ( 30.6 cm x 21.4 cm )
|
