The Republic of Gamers consists only the best of the best. We offer the best hardware engineering, the fastest performance, the most innovating ideas, and we welcome the best gamers to join in.
In the Republic of Gamers, mercy rules are only for the weak, and bragging rights means everything. We believe in making statements and we excel in competitions. If your character matches our trait, then join the elite club, make your presence felt, in the Republic of Gamers.
|
|
Performance with Reliability
8 phase EL-Capless power design
Reliable Power Supply and Longer Component Life
The 8-phase cap-less Power design demonstrates two hardcore commitments of ROG products: ultimate overclocking capability, and ultimate reliability. The 8-phase power design yields unparalleled superiority in the overclocking arena, while the EL cap-less design removes any worries of capacitor problems once and for all.
Heat-Pipe
The most reliable thermal solution
The Crosshair Series´ sophisticated design of heat-pipe directs heat from the chipset to two VRM copper heatsinks where the temperature can be dissipated by system airflow. This design promises ultimate reliability and quietness.
Extreme Tweaker
One stop performance tuning shop
Extreme Tweakers is the one stop shop to fine-tune your system to optimal performance. No matter if you´re looking for frequency adjustment, over-voltage options, or memory timing settings, they´re all here!
Sound with Clarity
of your choice!
|
AI Clock Skew
AI Clock Skew automatically skews the memory clock signal timing, thus improving memory overclocking capability by 10 to 15%, depending on the memory features when users overclock memory frequency. Users can easily enjoy better memory overclocking without strenuously fine-tuning the clock signal timing. For professional users, they can still adjust each memory channel´s clock signal separately to reach the highest memory frequency.
|
AI NOS™
* Boost performance when you need it the most!
Applications such as 3D games and video editing demand a huge chunk of system resource. Inject "nitrous oxide" into your CPU! The patented AI NOS™ (Non-delay Overclocking System) technology intelligently detects system load and automatically boosts performance for the most demanding tasks. Unlike other dynamic overclocking techniques, AI NOS™ reacts much faster to satisfy your unending need for speeds .
|
PEG Link
* Boost graphics card performance for superior video quality
This latest technology, PEG (PCI Express Graphics) Link Mode, is a unique feature that enables users to boost graphics card performance for superior video quality. PEG Link allows users to raise GPU and VGA memory throughput via the motherboard BIOS the same way system bus and memory bus are tweaked. PEG Link Mode enables powerful video performance on DX8 and DX9 applications. ASUS engineers carefully fine-tuned the parameters for every single PCI-Express card to provide system stability during high-speed graphics operation.
|
ASUS O.C. Profile
The motherboard features the ASUS O.C. Profile that allows users to conveniently store or load multiple BIOS settings. The BIOS settings can be stored in the CMOS or a separate file, giving users freedom to share and distribute their favorite overclocking settings.
|
C.P.R.(CPU Parameter Recall)
When the system hangs due to overclocking failure, there is no need to open the case to clear CMOS data. Just simply restart the system, the BIOS would show the previous setting and then users can amend the CPU setting again.
|
| Other Innovative Features |
|
MyLogo3
The ASUS MyLogo 3 is the new feature present in the motherboard that allows you to personalize and add style to your system with customizable and animated boot logos.
|
ASUS EZ Flash 2
EZ Flash 2 is a user-friendly BIOS update utility. Simply launch this tool and update BIOS from a USB flash disk before entering the OS. You can update your BIOS only in a few clicks without preparing an additional floppy diskette or using an OS-based flash utility.
|
ASUS CrashFree BIOS 3
The ASUS CrashFree BIOS 3 allows users to restore corrupted BIOS data from a USB flash disk containing the BIOS file. This utility saves users the cost and hassle of buying a replacement BIOS chip.
|
SATA on the Go
This motherboard supports the next-generation hard drives based on the Serial ATA (SATA) 3Gb/s storage specification, delivering enhanced scalability and doubling the bus bandwidth for high-speed data retrieval and saves. The external SATA port located at the back I/O provides smart setup and hot-plug functions. Easily backup photos, videos and other entertainment contents on external devices.
|
Dual RAID
The south bridge incorporate six Serial ATA connectors with high performance RAID functions in RAID 0, 1, 5, 0+1, and JBOD. The Silicon Image 3132 controller provides another two external Serial ATA connectors for RAID 0, 1, and JBOD functions. This motherboard is the ideal solution to enhance hard disk performance and data back up protection without the cost of add-on cards.
|
Dual Gigabit LAN
The integrated dual Gigabit LAN design allows a PC to serve as a network gateway for managing traffic between two separate networks. This capability ensures rapid transfer of data from WAN to LAN without any added arbitration or latency.
|
IEEE 1394a interface
IEEE 1394a interface provides high speed digital interface for audio/video appliances such as digital television, digital video camcorders, storage peripherals & other PC portable devices.
|
|
GreenASUS
The motherboard and its packaging comply with the European Union´s Restriction on the use of Hazardous Substances (RoHS). This is in line with the ASUS vision of creating environment-friendly and recyclable products and packaging to safeguard consumers´ health while minimizing the impact on the environment.
|
NVIDIA Essential Vista
NVIDIA nForce ® -based motherboards are essential for accelerating the Windows Vista experience by offering an enriched 3D user interface, increased productivity, and vibrant photos as well as delivering uncompromising performance, quality, and reliability.
Specifications
| CPU |
AMD Socket AM2+ / AM2 Processors
Support AMD® Socket AM2+/ AM2 Phenom FX(2000MT/s)/Phenom(2000MT/s)/ Athlon 64 X2 / Athlon 64 FX / Athlon 64/ Sempron
AMD Cool 'n' Quiet™ Technology
AMD64 architecture enables simultaneous 32-bit and 64-bit computing
AMD Live!™ Ready |
| Chipset |
NVIDIA nForce 590 SLI MCP
|
| System Bus |
2000/1600 |
| Memory |
4 x DIMM, Max. 8 GB, DDR 800/667/533 ECC,Non-ECC,Un-buffered Memory
Dual Channel memory architecture
*When installing total memory of 4GB capacity or more, WindowsR 32-bit operation system may only recognize less than 3GB. Hence, a total installed memory of less than 3GB is recommended. |
| Expansion Slots |
1 x PCIe x16 slot with NVIDIA® SLI™ technology support, at full x16, x16 speed
1 x PCIe x4
3 x PCI 2.2
|
| Scalable Link Interface (SLI™) |
Support two identical NVIDIA SLI-Ready graphics cards
ASUS two-slot thermal design
ASUS PEG Link |
| Storage |
NVIDIA nForce 590 SLI MCP
1 xUltraDMA 133/100/66/33
6 xSATA 3 Gb/s ports
Support RAID 0,1,0+1,5,JBOD
Silicon Image® 3132 SATA controller
2 xExternal SATA n back I/O (SATA On-the-Go)
Support RAID 0,1,JBOD
|
| LAN |
Dual Gigabit LAN controllers support NVIDIA DualNet® technology NVIDIA nForce® 590 SLI™ MCP built-in dual Gigabit MAC with external Marvell PHY
Support Teaming Technology |
|
|
| USB |
10 USB 2.0 ports ports |
| Overclocking Features |
Extreme Tweaker
Intelligent overclocking tools
- ASUS PEG Link
- AI Overclocking (intelligent CPU frequency tuner)
- ASUS AI Booster Utility
- ASUS AI NOS (Non-delay Overclocking System)
- AI Clock Skew
- ASUS O.C. Profile: overclocking configuration-sharing tool
Overclocking Protection
- ASUS C.P.R.(CPU Parameter Recall)
Adjustable FSB/DDR2 ratio. Fixed PCI/PCIe frequencies |
| Special Features |
ASUS MyLogo 3
ASUS EZ Flash 2
ASUS CrashFree BIOS 3
EL I/O
ASUS Music Alarm
Onboard LED
Q-Connector
LCD Poster
ASUS Q-Connector
Onboard Switches: Power / Reset / Cls CMOS (at rear)
ASUS Q-Fan Plus
|
| Back Panel I/O Ports |
1 x PS/2 Keyboard
1 x PS/2 Mouse
2 x External SATA
1 x S/PDIF Out
1 x IEEE 1394a
2 x LAN(RJ45) port
4 x USB 2.0/1.1
1 x onboard LED switch
1 x LCD Poster
|
| Internal I/O Connectors |
3 x USB connectors supports additional 6 USB 2.0 ports
1 x Floppy disk drive connector
1 x IDE connector
6 x SATA connectors
1 x IEEE 1394a connector
1 x CPU Fan connector
1 x S/PDIF Out connector
1 x8-pin ATX 12V Power connector
24 Power connector
1 x EL I/O Shield Connector
1 x thermal sensor connector
Front panel audio connector
Chassis Intrusion connector
System Panel
|
| BIOS |
8 Mb Flash ROM
DMI 2.0
PnP
WfM
SM BIOS
Award BIOS
|
| Manageability |
WOL by PME,WOR by PME,Chasis Intrusion,PXE |
|
|
