| General |
| CPU |
- Socket 478 for Intel® Pentium® 4/Celeron® processor
- FSB 800/533 MHz
- Supports Hyper-Threading Technology
- Prescott support |
| Chipset |
- Northbridge: Intel® 915GL
- Southbridge: Intel® ICH6 |
| Memory |
- Dual Channel DDR memory technology
- Supports DDR400/333 non-ECC, un-buffered memory
- DIMM slots: 2
- Max. capacity of system memory: 2GB |
| BIOS |
- 4Mb AMI BIOS with ACPI, SM BIOS 3.0, PnP |
| Audio, Video and Networking |
| Graphics |
- Integrated Intel® Media Accelerator 900 in Intel® 915GL chipset, capable of supporting DirectX 9.0 related application
- Dynamic Vedio Shared Memory Max. 192MB |
| Audio |
- Realtek ALC850 8 channel AC'97 audio codec |
| LAN |
- Realtek RTL8100C PCI 10/100 Fast Ethernet controller
- 802.3u, WOL supported
- Supports PXE |
| Expansion / Connectivity |
| Slots |
- ASRock A.G.I. Express slot: Compaitble with PCI Express x16 VGA card
- Worldwide patent ASRock A.G.I.8X graphics upgrade slot (AGP8X/4X compatible)
- 2 x PCI slots( PCI 2.3 compliance)
- 1 x AMR slot |
| Connector |
- 4 x SATA 1.5Gb/s connectors
- 1 x ATA100/66 IDE connectors ( supports 2 x IDE devices)
- 1 x Floppy connector
- CPU/Chassis FAN connectors
- 20 pin ATX power connector
- 4 pin 12V power connector
- CD audio in header
- Front panel audio connector
- 2 x USB 2.0 header (to support 4 USB2.0 ports)
- 1x COM port header |
| Rear Panel I/O |
ASRock 8CH I/O Plus
- 4 x USB2.0 ports
- 1 x RJ45 LAN port
- 1 x VGA port
- 1 x PS2 Keyboard connector
- 1 x PS2 Mouse connectors
- 1 x Parallel port (LPT1)
- 1 x 8 channel Audio ports ( Line In/Out, Mic In) |
| Other Features / Miscellaneous |
| Unique Feature |
Hybrid Booster:
- CPU Frequency Stepless control
- ASRock U-COP
- Boot Failure Guard (B.F.G)
- AGP/PCI frequency control |
| Support CD |
- Drivers, Utilities, AntiVirus Software,ASRock PC DIY Demo |
| Accessories |
- Quick Installation Guide, Support CD, I/O shield
- Floppy/ATA 100 Cables
- 1 x SATA Data Cable
- 1 x SATA 1-to-1 Power Cable
- 1 x COM Port Bracket |
| Hardware Monitor |
- CPU Temperature Sensing
- Motherboard Temperature Sensing
- CPU Fan Tachometer
- Chassis Fan Tachometer
- Voltage Monitoring: +12V, +5V, +3.3V, Vcore |
| Form Factor |
- Micro ATX, 244mm x 218mm |
| OS |
- Microsoft® Windows® 2000/XP compliant |
| Certifications |
- FCC, CE, MS WHQL |
