N68C-S UCC AM2+ GF7025 2DDR2/2DDR3 mATX
Informacje dodatkowe
CPU:
- Support for Socket AM2+* / AM2 processors: AMD Phenom™ FX / Phenom / Athlon 64 FX / Athlon 64 X2 Dual-Core / Athlon X2 Dual-Core / Athlon 64 / Sempron processor
- Support for AM3 processors*: AMD Phenom™ II X6 / X4 / X3 / X2 / Athlon II X4 / X3 / X2 / Sempron processors
- Supports UCC feature (Unlock CPU Core)
- Supports AMD's Cool 'n' Quiet Technology
- FSB 1000 MHz (2.0 GT/s)
- Supports Untied Overclocking Technology
- Supports Hyper-Transport Technology
*If you use AM3 / AM2+ CPU on AM2 chipset motherboard, the system bus speed will downgrade from HT3.0 (5200 MT/s) to HT1.0 (2000 MT/s), but the CPU frequency will not be influenced.
MEMORY: Dual Channel DDR3/DDR2 memory technology*
- 2 x DDR3 DIMM slots**
- Supports DDR3 1600/[zasłonięte]/1066/800 non-ECC, un-buffered memory
- Max. capacity of system memory: 8GB***
- 2 x DDR2 DIMM slots
- Supports DDR2 1066****/800/667/533 non-ECC, un-buffered memory
- Max. capacity of system memory: 8GB***
*DDR3 and DDR2 are supported separately.
**DDR3 memory is only supported by installing AM3 cpu.
***Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® 32-bit OS. For Windows® 64-bit OS with 64-bit CPU, there is no such limitation.
****Support with AM3 / AM2+ CPU.
| Tabela parametryczna |
| Gniazdo procesora: |
- Socket AM2
- Socket AM2+
- Socket AM3
|
| Typ procesora: |
- AMD Athlon
- AMD Athlon X2
- AMD Athlon II X2
- AMD Athlon II X3
- AMD Athlon II X4
- AMD Sempron
- AMD Sempron X2
- AMD Phenom X3
- AMD Phenom X4
- AMD Phenom II X3
- AMD Phenom II X2
- AMD Phenom II X4
- AMD Phenom II X6
|
| FSB: |
1000 MHz |
| Zintegrowany procesor: |
nie |
| Producent chipsetu: |
nVidia |
| Typ chipsetu: |
GeForce 7025 / nForce 630a
|
| Rodzaj pamięci: |
|
| Liczba gniazd DDR2: |
2 szt. |
| Liczba gniazd DDR3: |
2 szt. |
| Częstotliwość szyny pamięci: |
- 533 MHz
- 667 MHz
- 800 MHz
- 1066 MHz
- 1333 MHz
- 1600 MHz
|
| Max. wielkość pamięci (GigaBajt) : |
8 GB |
| Złącza PCI: |
2 szt. |
| Złącza PCI-E 16x ver. 2.0: |
1 szt. |
| Złącza PCI-E 8x : |
Brak |
| Złącza PCI-E 4x : |
Brak |
| Złącza PCI-E 1x : |
1 szt. |
| Złącze AGP: |
Nie |
| Maksymalna ilość urządzeń SATA: |
4 |
| Maksymalna ilość urządzeń ATA: |
2 |
| RAID: |
tak |
| Szczegółowe dane o interfejsach dysków/napędów: |
- 4 x SATAII 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1, RAID 0+1, RAID 5 and JBOD), NCQ and "Hot Plug" functions
- 1 x ATA133 IDE connector (supports 2 x IDE devices)
|
| Zintegrowana karta graficzna: |
tak |
| Typ zintegrowanej karty graficznej: |
- Integrated NVIDIA GeForce 7025 graphics
- DX9.0 VGA, Pixel Shader 3.0
- Max. shared memory 256MB
- Supports D-Sub with max. resolution up to 1920x1440 @ 60Hz
|
| Karta dźwiękowa: |
5.1 CH HD Audio (VIA VT1705 Audio Codec)
|
| Interfejs sieciowy: |
10/100 Mbit/s |
| Złącza USB na tylnym panelu: |
4 |
| Złącza USB do wyprowadzenia z płyty: |
6 |
| FireWire (IEEE 1394): |
nie |
| Port COM: |
Tak |
| Port LPT: |
Nie |
| Interfejsy na tylnym panelu: |
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Serial Port: COM1
- 1 x VGA Port
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
- HD Audio Jack: Line in / Front Speaker / Microphone
|
| Złącza dostępne na płycie: |
- 4 x SATAII 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1, RAID 0+1, RAID 5 and JBOD), NCQ and "Hot Plug" functions
- 1 x ATA133 IDE connector (supports 2 x IDE devices)
- 1 x Floppy connector
- 1 x Print Port header
- CPU/Chassis/Power FAN connector
- 24 pin ATX power connector
- 4 pin 12V power connector
- CD in header
- Front panel audio connector
- 3 x USB 2.0 headers (support 6 USB 2.0 ports)
|
| Funkcje specjalne: |
- ASRock OC Tuner
- Intelligent Energy Saver
- Instant Boot
- ASRock Instant Flash
- ASRock OC DNA
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- ASRock AM2 Boost: ASRock Patented Technology to boost memory performance up to 12.5%
|
| Bios: |
- 8Mb AMI Legal BIOS
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- Supports jumperfree
- SMBIOS 2.3.1 Support
- CPU, VCCM, NB Voltage Multi-adjustment
|
| Format płyty: |
micro ATX |
| Wymiary: |
24.4 cm x 20.8 cm
|
| Akcesoria w zestawie: |
- Quick Installation Guide, Support CD, I/O Shield
- 2 x SATA Data Cables (optional)
|
