1 x COM Port Header
1 x Chassis Intrusion Header
1 x TPM Header
1 x Power LED Header
2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)
3 x Chassis Fan Connectors (1 x 4-pin, 2 x 3-pin)
1 x Power Fan Connector (3-pin)
1 x 24 pin ATX Power Connector
1 x 8 pin 12V Power Connector (Hi-Density Power Connector)
1 x SLI/XFire Power Connector
1 x Front Panel Audio Connector
3 x USB 2.0 Headers (Support 6 USB 2.0 ports)
1 x USB 3.0 Header by AMD A88X (Bolton-D4) (Supports 2 USB 3.0 ports)

1 x PS/2 Mouse/Keyboard Port
1 x D-Sub Port
1 x DVI-D Port
1 x HDMI Port
1 x Optical SPDIF Out Port
3 x USB 2.0 Ports
1 x Fatal1ty Mouse Port (USB 2.0)
2 x USB 3.0 Ports (AMD A88X (Bolton-D4))
2 x USB 3.0 Ports (ASMedia ASM1042A)
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
1 x Clear CMOS Switch with LED
HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone

8 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5 and RAID 10), NCQ, AHCI and Hot Plug

ASRock F-Stream
ASRock Instant Boot
ASRock Instant Flash
ASRock APP Charger
ASRock XFast RAM
ASRock Crashless BIOS
ASRock OMG (Online Management Guard)
ASRock Internet Flash
ASRock UEFI System Browser
ASRock UEFI Tech Service
ASRock Dehumidifier Function
ASRock Easy RAID Installer
ASRock Easy Driver Installer
ASRock Interactive UEFI
ASRock Fast Boot
ASRock X-Boost
ASRock Restart to UEFI
ASRock USB Key
ASRock Key Master
ASRock FAN-Tastic Tuning
Hybrid Booster:
- ASRock U-COP

Quick Installation Guide, Support CD, I/O Shield
2 x SATA Data Cables

Integrated AMD Radeon™ R7/R5 Series Graphics in A-series APU
