| ZÅ‚ącza dostępne na pÅ‚ycie |
- 1 x IR Header
- 1 x COM Port Header
- 1 x Chassis Intrusion Header
- 1 x Power LED Header
- 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)
- 3 x Chassis Fan Connectors (1 x 4-pin, 2 x 3-pin)
- 1 x Power Fan Connector (3-pin)
- 1 x 24 pin ATX Power Connector
- 1 x 8 pin 12V Power Connector
- 1 x XFire Power Connector
- 1 x Front Panel Audio Connector
- 3 x USB 2.0 Headers (Support 6 USB 2.0 ports)
- 1 x USB 3.0 Header by AMD A88X (Bolton-D4) (Supports 2 USB 3.0 ports)
- 1 x Dr. Debug with LED
- 1 x Power Switch with LED
- 1 x Reset Switch with LED
- 1 x BIOS Selection Switch
|
| Karta dźwiękowa |
- 7.1 CH HD Audio with Content Protection (Realtek ALC1150 Audio Codec)
- Premium Blu-ray Audio support
- Supports Purity Sound™
- 115dB SNR DAC with differential amplifier
- TI NE5532 Premium Headset Amplifier (Supports up to 600 ohm headsets)
- Direct Drive Technology
- EMI shielding cover
- PCB isolate shielding
- Supports DTS Connect
|
| Interfejsy na tylnym panelu |
- 1 x PS/2 Mouse/Keyboard Port
- 1 x D-Sub Port
- 1 x DVI-D Port
- 1 x HDMI-Out Port
- 1 x HDMI-In Port
- 1 x DisplayPort
- 1 x Optical SPDIF Out Port
- 2 x USB 2.0 Ports
- 1 x eSATA Connector
- 2 x USB 3.0 Ports (AMD A88X (Bolton-D4))
- 2 x USB 3.0 Ports (ASMedia ASM1042)
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
- HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone
|
| Bios |
- 2 x 64Mb AMI UEFI Legal BIOS with multilingual GUI support (1 x Main BIOS and 1 x Backup BIOS)
- Supports Secure Backup UEFI Technology
- Supports "Plug and Play"
- ACPI 1.1 Compliant wake up events
- Supports jumperfree
- SMBIOS 2.3.1 support
- DRAM, VDDP, VDDR Voltage multi-adjustment
|
| Szczegółowe dane o interfejsach dysków/napędów |
7 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5 and RAID 10), NCQ, AHCI and Hot Plug
|
| ZÅ‚ącza PCI-E 8x |
Nie |
| Funkcje specjalne |
- ASRock A-Tuning
- ASRock Instant Boot
- ASRock Instant Flash
- ASRock APP Charger
- ASRock XFast USB
- ASRock XFast LAN
- ASRock XFast RAM
- ASRock Crashless BIOS
- ASRock OMG (Online Management Guard)
- ASRock Internet Flash
- ASRock UEFI System Browser
- ASRock UEFI Tech Service
- ASRock Dehumidifier Function
- ASRock Easy RAID Installer
- ASRock Easy Driver Installer
- ASRock Interactive UEFI
- ASRock Fast Boot
- ASRock X-Boost
- ASRock Restart to UEFI
- ASRock USB Key
- ASRock FAN-Tastic Tuning
- Hybrid Booster:
- ASRock U-COP
|
| RAID |
Tak |
| Maksymalna iloÅ›ć urządzeÅ„ SATA |
7 |
| Liczba gniazd DDR3 |
4 |
| ZÅ‚ącza PCI-E 16x ver. 2.0 |
1 |
| ZÅ‚ącza PCI-E 1x |
2 |
| ZÅ‚ącza PCI |
2 |
| ZÅ‚ącza PCI-E 4x |
Nie |
| Gniazdo procesora |
|
| Akcesoria w zestawie |
- Quick Installation Guide, Support CD, I/O Shield
- 4 x SATA Data Cables
|
| ZÅ‚ącze AGP |
Nie |
| Typ zintegrowanej karty graficznej |
- Integrated AMD Radeon HD 8000/7000 series graphics in A-series APU
- DirectX 11.1, Pixel Shader 5.6 with FM2+ CPU. DirectX 11, Pixel Shader 5.0 with FM2 CPU.
- Max. shared memory 2GB
- Multi VGA Output options: D-Sub, DVI-D, HDMI and DisplayPort Ports
- Supports Quad Monitor with FM2+ CPU. Supports Triple Monitor with FM2 CPU.
- Supports HDMI Technology with max. resolution up to 1920x1200 @ 60Hz
- Supports Dual-link DVI-D with max. resolution up to 2560x1600 @ 60Hz
- Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz
- Supports DisplayPort 1.2 with max. resolution up to 4K x 2K (4096x2400) @ 60Hz or 4K x 2K (4096x2160) @ 60Hz
- Supports DP++
- Supports Multi-Streaming
- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required)
- Supports Blu-ray Stereoscopic 3D with HDMI Port
- Supports AMD Steady Video™ 2.0: New video post processing capability for automatic jitter reduction on home/online video
- Supports HDCP with DVI-D, HDMI and DisplayPort Ports
- Supports Full HD 1080p Blu-ray (BD) playback with DVI-D, HDMI and DisplayPort Ports
|
| CzęstotliwoÅ›ć szyny pamięci |
- 1333 MHz
- 1066 MHz
- 1866 MHz
- 2133 MHz
- 1600 MHz
- 2400 MHz
|
| Maksymalna iloÅ›ć urządzeÅ„ ATA |
0 |
| Producent chipsetu |
AMD |
| Format płyty |
ATX |
| FireWire (IEEE 1394) |
Nie |
| Zintegrowany procesor |
Nie |
| Interfejs sieciowy |
1 x 10/100/1000 Mbit/s |
| Wymiary |
brak danych
|
| Zintegrowana karta graficzna |
Tak |
| Liczba portów USB 3.0 |
6 |
