Manufacturer

Cisco Systems, Inc

Manufacturer Part Number

ASA5580-20-BUN-K9

Product Type

Security appliance

Height (Rack Units)

4U

Installed Modules Qty (Max)

0 ( 6 )

Width

48.3 cm

Depth

67.3 cm

Height

17.6 cm

Weight

29.9 kg

Processor / Memory / Storage

RAM Installed ( Max )

8 GB

Flash Memory Installed (Max)

1 GB

Networking

Form Factor

Rack-mountable

Connectivity Technology

Wired

Network / Transport Protocol

IPSec

Performance

Firewall throughput : 6.5 Gbps
VPN throughput : 1 Gbps

Capacity

Concurrent sessions :[zasłonięte]10000
IPSec VPN peers : 5000
Virtual interfaces (VLANs) : 100
SSL VPN peers : 2
Security policies : 2

Features

Firewall protection, VPN support, load balancing, VLAN support

Encryption Algorithm

DES, Triple DES, AES

Connectivity Slots

Expansion Slot(s)

6 (total) / 6 (free) x Expansion Slot

Interfaces

2 x management - Ethernet 1000
2 x Hi-Speed USB - 4 PIN USB Type A
1 x management - console - RJ-45

Miscellaneous

Compliant Standards

CE, FCC Class A certified, CISPR 22 Class A, EN 60950, EN 61000-3-2, VCCI Class A ITE, IEC 60950, EN 61000-3-3, EN55022 Class A, UL 60950, CSA 22.2 No. 60950, FCC Part 15

Power Supply

Power Device

Power supply - hot-plug / redundant - plug-in module

Installed Qty

1

Max Supported Qty

2

Voltage Required

AC 120/230 V ( 50/60 Hz )

Power Provided

800 Watt
