CPU

• AMD® Athlon 64 X2, Athlon 64 and Sempron in the Socket AM2 package.
Please refer to CPU Support for compatible CPU; the above description is for reference only.

Hyper Transport Bus

• HyperTransport 1.0/2.0 supporting speed up to 1GHz (2000MT/s)

Chipset

• NVIDIA® Quadro NVS210S and nForce 430 Chipset

Main Memory

• Supports Dual DDR2 533/667/800
- 4 DDR2 DIMMs (240pin / 1.8V)
- Supports a maximum memory size up to 8GB.

Slots

• One PCI Express x16 slot.
• One PCI Express x1 slot.
• Two PCI slots (support 3.3v/5v PCI bus interface).

RAID Function

- SATA II 1~4 supports RAID 0 or RAID 1 mode.

Audio

• Chipset integrated by Realtek® ALC883
- Flexible 8-channel audio with jack sensing
- Compliant with Azalia 1.0 Spec

LAN

• Supports 10/100/1000 Fast Ethernet by Vitesse VSC8601

IEEE1394 / FireWire

• Chipset integrated by VIA® VT6308P
- Transfer rate is up to 400Mbps

Internal I/O Connectors

- ATX 24-pin power connector
- 4-pin ATX 12V power connector
- CPU / System / NB FAN connectors
- CD-in connector
- Serial port header
- IrDA infrared module header
- 1 x Floppy disk drive connector
- 4 x SATA II connectors
- 2 x ATA133 HD connectors
- 2 x USB 2.0 connector support additional 4 ports
- 1 x IEEE1394 connector support additional 1 ports (Optional)
- SPDIF-Out/ SPDIF-In connector
- Audio-Out connector
- Front panel connector
- Front panel audio connector
- Chassis intrusion switch connector
- Clear CMOS Jumper

Back Panel I/O Ports

- 1 x Parallel
- 1 x PS/2 Keyboard
- 1 x PS/2 Mouse
- 1 x VGA port
- 1 x DVI-D port
- 1 x IEEE1394 port
- 1 x Audio I/O (Line-in/Line-out/MIC)
- 4 x USB 2.0
- 1 x RJ45 LAN Jack

Dimension

• 24.4cm(L) x 24.4cm(W) Micro-ATX Form Factor

Mounting

• 8 mounting holes.
